August 22, 2019
M12 Circular Connectors expanded portfolio
CONEC has expanded its portfolio of M12 circular connectors to include the series of L-coded variants, thus offering a compact (30% less installation space requirement compared to a 7/8? overmolded connector), high-performance solution for industrial applications.
Electric drives, devices and servo motors are increasingly used in the field directly in the machine or plant. In addition to signals and data, more and more power has to be transmitted. Miniaturization in automation means that field devices and controllers are becoming ever smaller.
Connectors are field attachable:
Axial female and male variants are available for the connectors that can be assembled; these are designed with a screw connection for a strand cross-section of up to 2.5 mm?. The advantage of the screw contacts is that they can be assembled very easily and several times. The maximum connection cross section of 2.5 mm? and the very compact design (outer diameter 23 mm only) make it possible to transmit maximum power with this connector system.
All variants meet the IP67 protection class in mated condition. The new M12x1 L coding is standardized according to IEC 61076-2-111.
Benefits:
Applications:
Download the Circular Connector Overview from Conec HERE.
To contact our Sales Department for more information, please click HERE.
CONEC has expanded its portfolio of M12 circular connectors to include the series of L-coded variants, thus offering a compact (30% less installation space requirement compared to a 7/8? overmolded connector), high-performance solution for industrial applications.
Electric drives, devices and servo motors are increasingly used in the field directly in the machine or plant. In addition to signals and data, more and more power has to be transmitted. Miniaturization in automation means that field devices and controllers are becoming ever smaller.
Connectors are field attachable:
Axial female and male variants are available for the connectors that can be assembled; these are designed with a screw connection for a strand cross-section of up to 2.5 mm?. The advantage of the screw contacts is that they can be assembled very easily and several times. The maximum connection cross section of 2.5 mm? and the very compact design (outer diameter 23 mm only) make it possible to transmit maximum power with this connector system.
All variants meet the IP67 protection class in mated condition. The new M12x1 L coding is standardized according to IEC 61076-2-111.
Benefits:
- Compact design
- IEC 61076-2-111 standard compliant
- High current transmission
- Protection class IP67
- RoHS compliant
- Anti-vibration
- Easy assembly
Applications:
- Drive technology
- Automation engineering
- Industrial interfaces
- Assembly and production lines
- Cable assembly
- Process automation
- Servomotors
- Mechanical manufacturing
Download the Circular Connector Overview from Conec HERE.
To contact our Sales Department for more information, please click HERE.
