Fischer FiberOptic Series: ROBUST | OPTICAL PERFORMANCE | EASY CLEANING


With its miniature, circular, push-pull design, the Fischer FiberOptic Series enables device design for all sorts of indoor and outdoor environments - from defense, security, medical, and instrumentation, to robotics and Test & Measurement applications. Fischer FiberOptic solutions feature butt-joint optical contacts for high optical performances (0.2 dB/connection) with optimal design enabling precise lateral alignment and reduced insertion loss; single mode for long-distance applications (around 120 km) and in multimode for short-distance runs (3-5 km); multi-mode with UPC polishing (ultra physical contact); single mode with UPC and 8" APC polishing (angled physical contact) for ultra-low back reflection optimizing return loss.

Tested for harsh and extreme environments according to Norm IEC 61753-1 Cat. E, these fiber-optic cabled connectors are unbreakable by hand, sealed up to IP68 mated (IP67 unmated) -2m/24h and -300 m (1,000 ft) for the single fiber optic connector, have gas-tight panel receptacles (<10-6 mbar l/s), and resist corrosion (1,000 hours of salt mist, Brass Ni-Cr plated) and operating temperatures from -40oC to +85oC. Easy cleaning (with water), maintenance, and replacement are made possible with the ergonomic and user-friendly push-pull design, featuring ball-locking mating with 'click' proof, and a monoblock removable sleeve holder that supports in-field end-face cleaning and provides easy access to ferrules.

Fischer FiberOptic Series

KEY FEATURES

Best Performances

  • Butt-joint for high optical performances
  • 8o APC polishing to reduce return loss
  • IP68 sealing to 2m/24h mated (IP67 unmated)
  • Gas-tight panel receptacles (<10-6 mbar l/s)
  • High corrosion resistance (up to 1,000 hours of salt mist)
  • Operating temperatures from -40oC to +85oC
  • Convenient cleaning in the field
Optimized Designs

  • Single-mode and multimode versions
  • UPC and APC polishing
  • 1 to 4 optical channels
  • Hybrid versions
  • Push-pull locking with "click" proof
Here are the TECHNICAL SPECIFICATIONS for more information.

Contact our Sales Department for technical assistance and more information.
