Omnetics Nano 360® Circular Connectors
January 23, 2024
Omnetics News...

Nano 360® Circular Connectors

Omnetics' Nano Circular Connector Series utilizes Omnetics' rugged and reliable Flex-Pin contact system, is spaced on 25 mil (.64mm) centerlines, has a 9.0 mm mated length, and is specified to MIL-DTL-32139. These ultra-miniature circular connectors are ideal for industries that require small and durable performance.

At .025" pitch, Omnetics Nano 360® Circular connectors are the smallest mil-aero circular connectors on the market. Compared to larger circular configurations, we have reduced the size and weight by as much as 3x compared to standard .050" pitch circular connectors. Omnetics Nano 360® Circular connectors offer a number of standard designs and locking methods with pin counts ranging from 2 to 39 positions. The unique polarized-insulator allow for both plastic and metal shell connector design styles. Threaded couplings, metal and plastic breakaway shells and twist-lock housings are ready for both inline as well as panel mount interconnections. Thirty-two gauge standard Teflon insulated copper wire is also offered from stock that handles nearly 1 ampere of current per contact.

Omnetics Nano360-CircularConnectors

Nano 360® Plastic Circulars - Straight

Spaced on 25 mil (.64mm) centerlines and a 9.0 mm mated length, these connectors are the smallest Mil-Quality circulars available today. Extremely small outer diameters range from .122" (3.1 mm) to .217" (5.5 mm). With the ability to withstand high shock and vibration while maintaining their electrical integrity, these connectors are ideal for the most demanding applications. Gold plated contacts are polarized and shrouded by our unique Liquid Crystal Polymer housing, making these connectors capable of over 2,000 mating cycles. 6, 11, 16 & 28 positions housing sizes are available in pre-wired and solid straight tail versions.

Nano 360® Circulars Threaded Panel Mount - Wired/Cable

Omnetics nano series of circular connectors are now available with threaded metal housings giving them a positive lock and environmental seal. These are the smallest Mil-Quality circulars available today. With the ability to withstand high shock and vibrations while maintaining electrical integrity, they are ideal for the most demanding applications where size and weight are critical. These connectors can be configured with different levels of waterproof sealing up to IP-68. A variety of shell material and finishes are available including nickel plated brass and back oxide stainless steel.

These high density multi-position connectors are available in four shell sizes: 6, 11, 16 & 28 positions arranged on a .025" (.64 mm) pitch and are capable of 1 amp per contact. Utilizing a military quality contact system, these connectors are perfect for mission critical applications where size, weight and reliability are crucial.

Nano 360® Circulars Twist Lock Panel Mount - Discrete Wired/Cable (TYPE WD/WC)
Omnetics Nano series of circular connectors are now available with metal housings giving them a environmental seal. They have ability to withstand high shock and vibrations while maintaining electrical integrity. A variety of shell material and finishes are available. Sizes available 05, 12, 16 & 27.Wire Terminations available with Discrete wire and Cable.

Nano 360® Circulars Break Away Panel Mount - Discrete Wire/Cable

Omnetics nano series of circular connectors are now available in a break away configuration. These connectors are the smallest Mil-Quality circulars available today. With the ability to withstand high shock and vibrations while maintaining electrical integrity, the break away feature is ideal for the most demanding applications where size and ruggedness are valued. Designed with an extra retention spring, these connectors are engineered to release (break away) at a pre-determined force. These connectors are also available with added waterproof sealing up to IP-68 for the mated pair.

These high density multi-position connectors are available in sizes from 2-28 positions and have contacts arranged on a .025" (.64 mm) pitch. Utilizing a military quality contact system these connectors are ideal for applications where size, weight, and overall reliability are critical.

Omnetics Nano 360® Catalog

Contact our Sales Department for technical assistance and more information.
