Micro-D & Nano-D Connectors for Military & Aerospace
Micro-D connectors are emerging as the most often selected for cable interconnections in today's evolution of miniaturization.The need for ruggedized, miniature connectors that can enable quickly-changed modules, instruments, or even sensors and probes is becoming a norm.
The older micro-d connector is still extensively used as a standard in many existing designs and has established heritage with experienced designers in the industry. As new electronic technology and methods evolve, we see higher demand for module and component interchangeability. Often the change process must occur in the field or away from a technical bench. The existing military standards specify the micro-d connector size and format to ensure reliability and inter-mate capability from brand to brand.
The current problem: The current connectors require hand tools to lock and unlock the jack-screws that hold the mated pair in place.
The solution: Omnetics new Latching Micro-D connectors have been built onto the same placement as the old jack-screws but offer quick connection without any extra tools. Omnetics Micro-D subminiature connectors are QPL qualified and designed and manufactured to meet and exceed MIL-DTL-83513. The connector assembly is built to assure the highest performance through high shock and vibration applications as well as extreme environmental use. They use the proven beryllium copper spring pin to socket contact system plated with both nickel and gold that assures the highest quality for mating and de-mating and very low contact resistance. Pin and sockets are set at .050" center to center lines. The standard and COTs models are available in pin counts from 9 through 51 positions and come available in solder cup and wired as well as board mount configurations. The collection of Micro-D connectors also includes special high temperature versions, deep space versions with NASA qualified low outgassing, as well as mixed signal designs fabricated to match your application directly.
