August 6, 2018
Telegartner's SIMFix® series
The reliability of a mobile communication connection depends essentially on the antenna used. This must ensure reliable transmission and reception of data and signals even under the most difficult conditions and stress situations. Telegartner offers the suitable HF connectors as well as RJ45 and FO components for this.The RF connectors in the series SIMFix® are rugged connectors with threaded coupling for use in high performance transmitter applications. These connectors are waterproof and are suitable for external use. Furthermore, they are designed to provide excellent technical performance, especially concerning return loss and intermodulation.
The SIMFix® range includes RF connectors for terminating 1/4", 1/2" flex, 1/2", 7/8", 1-1/2" and 1-5/8" sized corrugated cables.
Assembly for all sizes is simple and reliable, thus guaranteeing constantly good electrical performance with regard to return loss and intermodulation. Ease of termination of the cables has been greatly enhanced by the use of specially developed tooling, which allows for exact stripping of the corrugated cables in the shortest of time.
Protection Step 1:
An O-ring on the outer jacket of the cable guarantees reliable protection against the ingress of water in normal applications of an undamaged cable.
Protection Step 2:
A special sealing to the outer conductor of the cable. Damage to the cable's outer jacket poses the danger that water will enter the connector between the outer jacket and the outer conductor of the cable. This is prevented by the additional sealing.
Protection Step 3:
Barrier sealed by protective steps taken on center contact. Massive destruction of the cable resulting in water ingress into the dielectric and possibly even into the inner conductor can destroy the following cable segment and even damage the base station, if water is able to seep through the connector.
