ALPS HSPPAD132A pressure sensor
Manufacturing industry applications for MEMS pressure sensors continue to increase based on the need for more tightly controlled processes with their associated quality control requirements. Increased monitoring of pressure and/or vacuum can detect the need for equipment maintenance prior to untimely failures that cause excessive downtime and increase manufacturing costs.
ALPS HSPPAD132A pressure sensor uses piezo-resistive bridge circuits formed on the silicon diaphragm. The device consists of a pressure and temperature sensor, 16b-bit analog to digital converter, control unit with MTP ROM, and 12C serial interface.
Why use a pressure sensor:
A pressure sensor is a device equipped with a pressure-sensitive element that measures the pressure of a gas or a liquid against a diaphragm made of stainless steel, silicon, etc., and converts the measured value into an electrical signal as an output.
Key Features:
Please click HERE to read the Pressure Sensor Application Note.
Download the Data Sheet HERE.
To contact our Sales Department for more information, please click HERE.
Manufacturing industry applications for MEMS pressure sensors continue to increase based on the need for more tightly controlled processes with their associated quality control requirements. Increased monitoring of pressure and/or vacuum can detect the need for equipment maintenance prior to untimely failures that cause excessive downtime and increase manufacturing costs.
ALPS HSPPAD132A pressure sensor uses piezo-resistive bridge circuits formed on the silicon diaphragm. The device consists of a pressure and temperature sensor, 16b-bit analog to digital converter, control unit with MTP ROM, and 12C serial interface.
Why use a pressure sensor:
A pressure sensor is a device equipped with a pressure-sensitive element that measures the pressure of a gas or a liquid against a diaphragm made of stainless steel, silicon, etc., and converts the measured value into an electrical signal as an output.
Key Features:
- Water-proof pressure sensor with temperature-compensated digital output
- 300 to 1100 hPa absolute pressure range
- I2C Interface
- 16-bit termperature data output
- Current consumption down to 9.5?A (1Hz Sampling)
- Supply voltage 1.7 to 3.6V
- Operating temperature range -10? to ?60?
- Pressure accuracy + or - 2hPa
- Noise 2Pa (RMS)
