CONEC Hybrid Connector

One connector instead of two or three, shorter assembly times, no cable tangle, less weight on the end device (motor, for example). These are the convincing arguments for the CONEC Hybrid connector series.

CONEC hybrid connectors are among the first products to comply with the future IEC 61076-2-118 standard.

• The individual wiring of stranded wires in a control cabinet is too time-consuming for you, are you looking for a system for decentralised control?
• You would like to finally put an end to "cable tangle" on the machine and save costs and material at the same time?
• You are looking for a system that guarantees the safety of an IEC standard?
• You need a system that allows you to plug in without errors and without the need for a complex occupancy plan?
• Are you looking for a connector system that can be securely locked without time-consuming screwing with a torque spanner?
• Do you need a connector solution that enables you to quickly exchange a module in a production line, for example?

One system, multiple application possibilities
CONEC Hybrid connector system for more efficiency in modular mechanical engineering

The CONEC Hybrid connector series combines power supply and data transmission in one connector. Different sizes (B12, B17, B23, B40) for various power classes from drives or devices offer maximum fl exibility. Whether for small DC drives or powerful servo drives, CONEC Hybrid connectors are the perfect solutions.

Locking of mated connector is secured with a bayonet fastener, so that a time-consuming screw connection by means of a torque wrench is no longer necessary. A quarter turn ensures a secure connection and IP67 protection class. It is important to note that the bayonet can only be locked, if the hybrid connectors are completely mated in. The risk of failure due to incompletely mated or unscrewed connectors is thus greatly reduced.

Advantages

• Space-saving by transmitting data and power via one single connector
• Modular system
• Reduced wiring
• Shorter assembly times
• Cost savings
• Fast and secure connection with bayonet locking
• Degree of protection IP67
• Improved diagnostic possibilities
• Compact and robust design

Fields of Application

• Drive technology
• Mechanical engineering
• Robotics
• Assembly and production lines
• Renewable energy

CONEC Hybrid Connector Series Catalog

Contact our Sales Department for technical assistance and more information.
